3E Security SB200 Slimline Solenoid Bolt Fail safe

This 3E Security slimline solenoid bolt door lock offers excellent level of security for such a compact solution with 450kgs holding force.fail safe

From £122.39 (Inc. VAT)


Product Specification:

Please refer to the product information below if you are unsure of which product to choose; alternatively please call, email or live chat us!

Fail Safe
12V DC & 24V DC
Vertical or Horizonal
Double Monitored
Stainless Steel
3E SB200



The 3E Security slimline solenoid bolt door lock is ideal for high security applications that require very flexible installation in timber or metal doors. The solenoid bolt lock can be fixed in a horizontal or vertical position and is a fail safe lock, double monitored with 24V DC and 24V DC. The electric solenoid will work with all types of access control or door entry systems.


  • Double monitored, fail safe lock
  • Operating voltage 12 and 24V DC
  • Current draw 0.35 amps at 12V DC, 0.17 amps at 24V DC
  • Holding force up to 450kgs
  • Suitable for timber or metal doors, and double action doors
  • Can be fixed in horizontal or vertical position with optional surface housing available

Buy the 3E Security SB200 slimline solenoid bolt lock online at Electric Locking Systems with worldwide delivery, same day dispatch and free technical support.

Choose Options & Add to basket
