Alpro AL110 Electric Strike Locks

View the ALPRO electric strike locks - AL110 series, an ANSI style security lock with short or long faceplates to use in timber or metal applications.
TO ORDER THE SASHLOCK FACEPLATE ACCESSORIES PLEASE SEE PRODUCT INFORMATION AND THE DIMENSION DRAWINGS ARE THERE TO ASSIST OR FEEL FREE TO CALL OR EMAIL FOR ADVICE

From £17.99£114.99 (Excl. VAT)

By:



Choose your product options:

Please refer to the product information below if you are unsure of which product to choose; alternatively please call, email or live chat us!

Quantity

+

TO ORDER THE SASHLOCK FACEPLATE ACCESSORIES PLEASE SEE PRODUCT INFORMATION AND THE DIMENSION DRAWINGS ARE THERE TO ASSIST OR FEEL FREE TO CALL OR EMAIL FOR ADVICE

View the ALPRO electric strike locks – AL110 series at Electric Locking Systems, an ANSI style security lock with short or long faceplates to use in timber or metal applications.
The electric door strike is designed with a moveable stainless steel jaw, which when an electrical current is applied either opens or remains in the locked position. In this way the traffic using the door can be rigorously controlled. Monitored and lipless versions available.
Features:
• High Holding Force
• Simple Fail Safe/Fail Secure Changeover
• Weather Resistant IP56
• Easy Installation
• 6 Year Guarantee
• Will work in conjunction with access control and door entry systems
Specifications:
• 12/24v Selectable
• Stainless Steel Face Plate and Striker
• Holding Force
• 1,750kg (3,860lb) – factory tested
• Compact Cast Aluminium Body
• 35mm overall depth
• Deep Jaw
• Accepts 13mm latch bolt
• Low Current Consumption
• 200mA – 12v DC continuous (±15%)
• 100mA – 24v DC continuous (±15%)
• Simple Fail Safe/Fail Secure Changeover
• Easy Installation
• Stick on/Peel off template
• Monitored and lipless versions available
• Weather Resistant
• IP56 Protection as Standard
• Options
• ANSI short and ANSI long faceplates
• Extension lips – 15, 25, 50 and 75mm (pre-drilled strike body)
• Spares
• Replacement changeover pin
• Approvals
• EN61000-6-3:2007
• EN50130-4:1995 + A1
• EN50130-4:1998 + A2
• EN50130-4:2003
